ThermoLinc Lease Security Deposit

Advance Alarm function :

• Immediate Alarm: Real-time email, text message, and automated phone call alarms to multiple recipients if any parameter falls below or exceeds the set threshold.
• Delay for Alarm: Up to 24-hour delay can be set to notify only if measurements remain out of range for a specified period, reducing false alarms.
• Trend Detection: Sends email alarms if a drift beyond a certain adjustable percentage is detected over a specific adjustable period.

Recording (Sample) Intervals: Adjustable from 1 minute to 30 minutes (down to 2 seconds or up to 120 minutes upon request).

Powerful Advanced PWA: Automatically detects screen size and loads the mobile or desktop version. Provides data analysis and generates various reports tailored to different use cases and industries.

Remote Access: Records are securely stored in the cloud and accessible from any device without range limits.

Sharing Access: Unlimited team members can access alarms, records, reports, and graphs.

Data Safety and Security: Data is stored in a tamper-proof format (FDA-compliant) and backed up daily.

End-to-End Encryption: All transactions between the logger, server, and users are fully encrypted.

Digital Tracing: All interactions between the user, web application, and data logger are securely recorded in a tamper-proof format for future audits.

Hardware

IEEE 802.11b/g/n
FCCID WiFi Products: 2AC7Z-ESP32WROOM32E
FCCID Cellular Products: 2AC7Z-ESP32WROOM32E + 2AJYU-SIM7000G
CE
EN 61326-1
EN 61010
EN 12830
ROHS

Application

FDA CFR 21 part 11

Port I: Not in use

Port II Dry Contact Input (Optional): This port can connect to any source of digital (dry contact) input, such as a door magnet, duress button, or PLC digital output. When the circuit is closed, the device sends an audible and visible alarm (a red flash and beep every 5 seconds) and dispatches an email, text message, and automated phone call to an unlimited number of recipients. The device continues to beep and flash as long as the contact remains closed and repeats the reminder alarm every hour until the contact is opened. Once the contact is opened, the device syncs again.

Port III – Flood sensor (Optional): Up to 100 meters (330ft) all long sensitive flood sensor

.

Device only (Excluding External Sensors)

Net Weight: 185 gr (6.5 Oz)

Gross Weight: 200 gr (7 Oz)

Dimensions: H=133, W=42, L=52 mm (H=5¼, W=1⅝ L=2 inches)

Package Dimensions: H=140, W=46, L=57 mm (H=5½, W=2, L=2¼ inches)
